1. Ratchet head that can be tightened both clockwise and counter clockwise

2. LED light that prompts when the set target torque value reaches the proportion during use

3. Beep alarm to remind the proportion of operating torque value

4. Display screen with backlight, very clear

5. < M >You can preset 6 different target values in advance, or press and hold to lock the button function

6. <↑ ↓>Adjust the value size and select switch

7. < C >ON-OFF     Display Zero

8. < U >Choose to transform four different torque units

9. Integrated soft rubber wrapped handle

Two working display modes

PEAK——During use, the screen displays the maximum torque value achieved during the process in real-                       time.

TRACK——During use, the screen displays the current torque value in real-time, and returns to zero after                        unloading.

In both operating modes, the alarm function will prompt based on the preset target value.

After setting the target torque value, the LED light and buzzer alarm will prompt at three points of 85%90%100% during the afterburner.

For example, setting a target of 100N. m

When the Torque reaches 85N. m, the first green light will light up and the buzzer will sound.

When the Torque reaches 90N. m, the second green light will light up and the buzzer will sound.

When the Torque reaches 100N. m, two red lights light up together and the buzzer sounds continuously.

It is equipped with a ratchet head that can be used both clockwise and counterclockwise.

Integrated Surrounding Ratchet Assembly.

45 teeth——Better withstand torque loading, Simultaneously and accurately transmit torque.
